BS PD CEN/TS 13149-7:2015

BS PD CEN/TS 13149-7:2015 specifies the general rules for an on-board data communication system between the different systems that may be used within public transport vehicles. This includes operational support systems, passenger information systems, fare collection systems, etc.

This Technical Specification describes:

• the requirements for an on board IP network;
• the overview architecture and components for an IP based on-board network;
• the modular structure of the network architecture;
• the Service Oriented Architecture (SOA) approach, and approach to defining services.

Systems directly related to the safe operation of the vehicle (including propulsion management, brake systems, door opening systems) are excluded from the scope of this Technical Specification and are dealt with in other standardization bodies. However, the architecture described in this Technical Specification may be used for support services such as safety information messages. Interfaces to safety-critical systems should be provided through dedicated gateways with appropriate security provisions; for the purposes of this Technical Specification, these are regarded as simply external information sources.

This Technical Specification is designed primarily for vehicles with a fixed primary structure, where networks can be installed on a permanent basis and the system configuration task consists largely of the integration, adjustment or removal of the functional end systems that produce and/or consume data. Public transport vehicles consisting of units linked temporarily for operational purposes (specifically, trains in which individual engines, cars or consists are routinely connected and disconnected) require additional mechanisms to enable the communications network itself to reconfigure. Such mechanisms are provided through other standards, notably the IEC 61375 series. (See also 5.9.)


Cross References:
EN 13149-1:2004
EN 13149-2:2004
CEN/TS 13149-3:2007
EN 13149-4:2004
EN 13149-5:2004
CEN/TS 13149-6:2005
CEN/TS 13149-7:2015
CEN/TS 13149-8:2013
prCEN/TS 13149-9
CEN/TS 16614
EN 12896
CEN/TS 15531
ISO/IEC 7498-1:1994
IEEE 802.3
RFC793
RFC768
RFC791
RFC959
RFC1035
RFC1123
RFC1323
RFC1918
RFC2131
RFC2181
RFC2616
RFC2460
RFC2782
RFC3177
RFC3550
RFC3927
RFC4253
RFC4291
RFC4330
RFC4862
RFC5905
RFC6762
RFC6763
RFC7159


All current amendments available at time of purchase are included with the purchase of this document.
