BS PD IEC TR 61189-5-506:2019

Test methods for electrical materials, printed boards and other interconnection structures and assemblies-General test methods for materials and assemblies. An intercomparison evaluation to implement the use of fine-pitch test structures for surface insulation resistance (SIR) testing of solder fluxes in accordance with IEC 61189-5-501

BSI Group, 07/18/2019

Publisher: BS

File Format: PDF

$125.00$251.46

Description

Published:18/07/2019

Pages:26

File Size:1 file , 5.1 MB

Note:This product is unavailable in Ukraine, Russia, Belarus

This Technical Report is an intercomparison supporting the development of IEC 61189-5-501 in relation to the SIR method. This document sets out to validate the introduction of a new 200-µm gap SIR pattern, and was benched marked against existing SIR gap patterns of 318 µm and 500 µm.

Cross References:
IEC 60068-2-20:2008
IEC 61189-5-501

All current amendments available at time of purchase are included with the purchase of this document.
