BS PD IEC TR 63127:2019

System design is the basis of construction and operation of HVDC systems. It defines the overall philosophy for the HVDC transmission system and enables the ratings and specifications for the equipment integrated in the project.

This document focuses on the system design of converter stations. It is applicable to point-topoint and back-to-back HVDC systems based on line-commutated converter (LCC) technology.

This document provides guidance and supporting information on the procedure for system design and the technical issues involved in the system design of HVDC transmission projects for both purchaser and potential suppliers. It can be used as the basis for drafting a procurement specification and as a guide during project implementation.

Cross References:
IEC 60633
IEC TR 60919-3
IEC 61803
IEEE 1124:2003
IEC 60287 (all parts)
IEC TS 61973
IEC TR 63014-1
CIGRE TB 518
CIGRE TB 352
IEC TS 62344
CIGRE TB 92
IEC 60060-1
IEC TR 60919-2
CIGRE TB 68
CIGRE TB 115
IEC 60076-6
IEC 60700-1
IEC TR 62001 (all parts)
IEC/IEEE 65700-19-03
CIGRE TB 563
IEC/IEEE 60076-57-129
IEC 60071-5
IEC TR 60919-1:2010


All current amendments available at time of purchase are included with the purchase of this document.
