BS PD IEC/TS 62735-1:2015

Direct current (DC) plugs and socket-outlets for information and communication technology (ICT) equipment installed in data centres and telecom central offices-Plug and socket-outlet system for 2,6 kW

BSI Group, 09/30/2015

Publisher: BS

File Format: PDF

$215.00$431.80


Published:30/09/2015

Pages:126

File Size:1 file , 3.5 MB

Note:This product is unavailable in Ukraine, Russia, Belarus

BS PD IEC/TS 62735-1:2015, which is a Technical Specification, applies to plugs and fixed socketoutlets for class I equipment with two active contacts plus an earthing contact, a rated power of 2,6 kW and a rated voltage range from 294 V to 400 V d.c. They are intended to power d.c. information and communication technology equipment only, products according to IEC 60950.

The accessories according to this part of IEC 62735 are intended to be used by ordinary persons in data centres only where the value of the d.c. voltage distribution system is defined as follows:
  • 380 V with a tolerance of ±20 V for installations with no backup battery or with a voltage regulation system;
  • 380 V with a voltage range of 294 V to 400 V for installations with a backup battery where voltage regulation is not guaranteed;
  • the voltage value between each live conductor and earth does not exceed 200 V d.c. during normal operation;
  • there are two abnormal voltage ranges (duration below 10 min):
    • 260 V up to 294 V, and
    • above 400 V to 410 V.
The maximum current of the plug and the socket-outlet is
  • 6,5 A when the voltage between live contacts is 400 V d.c.,
  • 8,8 A when the voltage between live contacts is 294 V d.c.
and can rise up to 10 A when the voltage between live contacts decreases to 260 V d.c. for 10 min maximum.

The voltage between live conductors can fall down to 260 V d.c. when the voltage discharge value of the battery reaches the disconnecting level. The consequence is that the current increases accordingly.

The accessories according to this part of IEC 62735 do not require maintenance.

Plugs and socket-outlets covered by this part of IEC 62735 are intended for use in circuits where
  • basic protection,
  • an overcurrent protection (of 8,8 A or less for each socket-outlet or multiple socket-outlet),
  • the fault protection (indirect contact protection), and
  • additional protection
    are already assured.

Cross References:
IEC 60050-151:2001
IEC 60068-2-31
IEC 60227
IEC 60245
IEC 60352-2
IEC 60423
IEC 60512-12-1
IEC 60512-12-2
IEC 60529
IEC 60695-2-11
IEC 61032
IEC 61210
ISO 1456
IEC 60068-2-30
IEC 60364
IEC 60417
ISO/IEC Guide 51


All current amendments available at time of purchase are included with the purchase of this document.
