BS PD IEC/TS 62786:2017

BS PD IEC/TS 62786:2017 provides principles and technical requirements for distributed energy resources (DERs) connected to the distribution network. It applies to the planning, design, operation and connection of DERs to distribution networks. It includes general requirements, connection scheme, choice of switchgear, normal operating range, immunity to disturbances, active power response to frequency deviation, reactive power response to voltage variations and voltage changes, EMC and power quality, interface protection, connection and start to generate electrical power, active power management, monitoring, control and communication, and conformance tests.

This document specifies interface requirements for connection of generating plants with the distribution network operating at a nominal frequency of 50 Hz or 60 Hz.

DERs include distributed generation and permanently connected electrical energy storage in the form of synchronous generators, asynchronous generators, converters, etc., connected to the medium voltage (MV) or low voltage (LV) distribution network.

NOTE Mobile electrical energy storage devices (e.g. electrical vehicles) are under consideration for future editions.

The requirements of this document can be superseded by laws and regulations where applicable.


Cross References:
IEC 61000
IEC TS 62749:2015 IEC 60050-521:2002 Ed 2
IEC 62559-2:2015 ED1
IEC 61850-7-420:2009
IEC 60038:2009
IEC 60870-1-4:1994
IEC 60050-151:2001 Ed 2
IEC TR 61850-90-8:2016
IEC 60870-6-503:2014
IEC 61508-7:2010 Ed 2
IEC 62116:2014
IEC 61508-2:2010 Ed 2
CAN/CSA-C22.2 No.257-06
IEEE Std 1547.2:2008
IEEE Std 1547.3:2007
BDEW 2008
IEEE Std 1547.4:2011
European Commission Regulation (EU) 2016/631
IEC TR 60870-1-1
CAN/CSA-C22.3 No.9-08
NB/T 32015:2013
ENA ER G59/3-2
VDE-AR-N 4105:2011
IEEE Std 1547:2003
IEEE Std 1547.1:2005
IEC 61000-4-15:2010 Ed 2
IEC TS 62351-5:2013
IEC 60870-6-802:2014
IEC 61968-1:2012
IEC/TR 62746-2:2015 ED1
IEC 61557-1:2007
IEC 60050-192:2015 ED1
IEC 62109-1:2010
IEC 61000-3-15:2011 Ed 1
IEC 61508-3:2010 Ed 2
IEC 60050-826:2004
CLC/TS 50549-2:2015
CLC/TS 50549-1:2015
IEC TR 61508-0:2005
IEC TS 61850-80-1:2016
IEC TR 62357-1:2016
IEC 62894:2014
IEC 60870-1-2:1989
IEC 60870-6-702:2014
EN 50438:2013
IEC 61400-21:2008


All current amendments available at time of purchase are included with the purchase of this document.
