BS PD IEC/TS 63066:2017

Low-voltage docking connectors for removable energy storage units

BSI Group, 04/30/2017

Publisher: BS

File Format: PDF

$175.00$350.52


Published:30/04/2017

Pages:54

File Size:1 file , 3.6 MB

Note:This product is unavailable in Ukraine, Russia, Belarus

BS PD IEC/TS 63066:2017 applies to docking connectors (hereinafter referred to as accessories) incorporated in or fixed to electrical equipment, intended to connect removable energy storage units to a dedicated electric power conversion unit, to an energy consuming unit or to another energy storage unit.

These accessories are intended for DC and may include an earth1 contact and/or optional auxiliary contacts for signaling and data. These accessories have a rated current of up to 800 A and rated operating voltages not exceeding 1 000 V DC.

These accessories are not suitable for mating or unmating under load. These accessories are intended to be installed by instructed persons (IEC 60050-195:1998, 195-04-02) or skilled persons (IEC 60050-195:1998, 195-04-01) only.

The list of preferred ratings is not intended to exclude other ratings.

This document applies to accessories for use under environmental conditions as described in Clause 32.

These accessories are intended to be connected to current carrying parts in copper or copper alloy only, plated or not plated.

This document also applies to accessories intended to be used at extra-low voltage.

In locations where special conditions prevail, for example on board vehicles, additional requirements may apply.

These accessories are intended to be used with a specific charging system.

NOTE For conditions other than operation, additional requirements could be applicable, for instance IEC 62133 and the UN Recommendations on the Transport of Dangerous Goods section 38.338.3.


Cross References:
IEC 60309-1:1999
IEC 60309-1:1999/AMD1:2005
IEC 60309-1:1999/AMD2:2012
IEC 60068-2-1
IEC 60068-2-2
IEC 60068-2-14
IEC 60068-2-30
IEC 60068-2-38
IEC 60068-2-52
IEC 60068-2-60
IEC 60309-1:1999
IEC 60309-1:1999/AMD1:2005
IEC 60309-1:1999/AMD2:2012
IEC 60352
IEC 60417
IEC 61140:2016
IEC 61373:2010
ISO/IEC TR 29106:2007
ISO/IEC TR 29106:2007/AMD1:2012
IEC 60050-195
IEC 60884-1:2002
IEC 60884-1:2002/AMD1:2006
IEC 60884-1:2002/AMD2:2013
IEC 62133
ISO 61750-3:2012


All current amendments available at time of purchase are included with the purchase of this document.
