BS PD ISO/TR 10828:2015

Worm gears. Worm profiles and gear mesh geometry

BSI Group, 09/30/2015

Publisher: BS

File Format: PDF

$200.00$401.32


Published:30/09/2015

Pages:106

File Size:1 file , 3.4 MB

Note:This product is unavailable in Ukraine, Russia, Belarus

In BS PD ISO/TR 10828:2015, thread profiles of the five most common types of worms at the date of publication are described and formulae of their axial profiles are given.

The five worm types covered in this technical report are designated by the letters A, C, I, K and N.

The formulae to calculate the path of contact, the conjugate profile of the worm wheel, the lines of contact, the radius of curvature and the velocities at points of contact are provided. At the end the application of those formulae to calculate parameters used in load capacity calculations are provided.


Cross References:
ISO 1122-2
ISO 701
ISO/TR 14521
BS 721-2:1983


All current amendments available at time of purchase are included with the purchase of this document.
