BS PD ISO/TS 13399-72:2016

Cutting tool data representation and exchange-Creation of documents for the standardized data exchange. Definition of properties for drawing header and their XML-data exchange

BSI Group, 07/31/2016

Publisher: BS

File Format: PDF

$125.00$251.46


Published:31/07/2016

Pages:32

File Size:1 file , 2.2 MB

Note:This product is unavailable in Ukraine, Russia, Belarus

BS PD ISO/TS 13399-72:2016 defines the necessary text elements of a drawing frame and determines a standardized data exchange format. Therefore, the effort is reduced for the maintenance of documentation because the content of a drawing header is mated into a specific drawing frame by means of using XML technology and an individual mapping table. The benefit of this concept for manufacturer/supplier and end user is the advantage of a central maintenance of the appropriate templates.

This part of ISO/TS 13399 covers the following:
  • identification and definition of the data fields;
  • identification and definition of the structure of the data fields;
  • structure of the data exchange file.
The standardization of drawing formats, e.g. drawing frame, structure of the bill of material, are outside the scope of this part of ISO/TS 13399 which is rather more intended to standardize the data exchange of the product documentations.

The following are outside the scope of this part of ISO/TS 13399:
  • layer settings as defined in ISO/TS 13399-70;
  • structure of the tool documentation as defined in ISO/TS 13399-71;
  • applications where these standard data may be stored or referenced;
  • concept of the classification of cutting tool data and their properties;
  • concept of the design of 2D drawings for cutting tools;
  • concept of the design of 3D models for cutting tools;
  • application data for the use of those cutting tools;
  • information about the reconditioning of cutting tools;
  • information about additional application and usage data (e.g. coolant supply).

Cross References:
ISO 10303-28
ISO 5610-9
ISO 13399-1:2006
ISO/TS 13399-2
ISO/TS 13399-3
ISO/TS 13399-4
ISO/TS 13399-70
ISO/TS 13399-71


All current amendments available at time of purchase are included with the purchase of this document.
