CSA 11.3:19/ANSI Z21.63:19

Portable type gas camp heaters

CSA Group, 09/01/2019

Publisher: CSA

File Format: PDF

$175.00$350.00


Published:01/09/2019

Pages:65

File Size:1 file , 1.1 MB

Note:This product is unavailable in Russia, Ukraine, Belarus

Scope

1.1
This Standard applies to unvented portable type gas camp heaters of the catalytic and infrared type only up to and including a maximum input of 12,000 Btu/hr (3 517 w) using propane, butane, and liquefied petroleum gas mixtures thereof, and intended for outdoor use.

1.2
This Standard applies to portable type gas camp heaters having a:
a) regulated pressure; or
b) non-regulated pressure.

1.3
Heaters and components employing materials or having forms of construction differing from those detailed in these provisions may be examined and tested according to the intent of the provisions, and if found to be satisfactorily equivalent, may be given recognition.

1.4
This Standard applies to heaters constructed entirely of new, unused parts and materials.

1.5
All references to psi throughout this Standard are to be considered gauge pressures unless otherwise specified.

1.6
All accessories recommended by the manufacturer for use with appliances tested to this Standard are to be supplied with the appliance.

1.7
If a value for measurement as given in this Standard is followed by an equivalent value in other units, the first stated value is to be regarded as the specification, except as noted in Clause A.2.

1.8
Annex A, Items Unique to Canada, contains clauses that are unique to Canada.

1.9
Clause 2, Reference publications, contains a list of standards specifically referenced in this Standard, and sources from which these standards may be obtained.

1.10
This Standard contains SI (Metric) equivalents to the yard/pound quantities, the purpose being to allow the standard to be used in SI (Metric) units. (IEEE/ASTM SI 10 is used as a guide in making metric conversion from yard/pound quantities.) If a value for a measurement and an equivalent value in other units are given, the first stated is to be regarded as the requirement. The given equivalent value may be approximate. If a value for a measurement and an equivalent value in other units are both specified as a quoted marking requirement, the first stated unit, or both are to be provided.

1.11
In this Standard, ""shall"" is used to express a requirement, i.e., a provision that the user is obliged to satisfy in order to comply with the standard; ""should"" is used to express a recommendation or that which is advised but not required; and ""may"" is used to express an option or that which is permissible within the limits of the standard. Notes accompanying clauses do not include requirements or alternative requirements; the purpose of a note accompanying a clause is to separate from the text explanatory or informative material. Notes to tables and figures are considered part of the table or figure and may be written as requirements. Annexes are designated normative (mandatory) or informative (non-mandatory) to define their application.
