CSA A231.1:19/A231.2:19

Precast concrete paving slabs/Precast concrete pavers, Includes Update No. 1 (2020)

CSA Group, 11/01/2019

Publisher: CSA

File Format: PDF

$75.00$150.00


Published:01/11/2019

Pages:61

File Size:1 file , 5.8 MB

Note:This product is unavailable in Russia, Ukraine, Belarus

Preface:

This is the third edition of CSA A231.1/CSA A231.2, Precast concrete paving slabs/Precast concrete pavers. It supersedes the previous editions published in 2014 and 2006.

The following are the major changes to this edition of CSA A231.1/CSA A231.2:
a) Clause 4.6 of CSA A231.1: Requirements have been revised to be consistent to CSA A231.2.
b) Clause 4.7 of CSA A231.2: Requirements have been revised to be consistent to CSA A231.1.
c) Clause 5.1 of CSA A231.1 and CSA A231.2: Additional guidance has been included for segmental paving units that do not meet the definition of a slab or a paver.
d) Clause 5.2 of CSA A231.1 and CSA A231.2: Additional guidance has been included for production control and frequency sampling for a given product and when there is a change in the mix design.
e) Clauses 5.3, 5.4, and 5.5 of CSA A231.1 and CSA A231.2: Requirements have been revised to be consistent to A231.2. Additional guidance on field sampling has been included.
f) Clause 5.6 of CSA A231.1 and CSA A231.2: Requirements have been updated for sample and specimen identification.
g) Clause 6.1.3 of CSA A231.1: Additional guidance has been included for the structural integrity of field samples at the time of installation.
h) Clause 6.1.4 of CSA A231.1: For consistency between CSA A231.1 and CSA A231.2, the requirements have been removed and reference to CSA A231.2, Clause 6.1.4, has been included.
i) Clause 6.1.5 of CSA A231.1 and CSA A231.2: Additional guidance has been included for visual inspection.
j) Clause 6.2 of CSA A231.2: Requirements have been revised to be consistent to CSA A231.1.
k) Clause 6.3 of CSA A231.1 and CSA A231.2: A new clause has been added to provide guidance on the basis for compliance.
l) Clause 7.1.1 of CSA A231.1: Requirements have been revised to be consistent to CSA A231.2.
m) Clause 7.1.3 of CSA A231.1 and A231.2: Humidity tolerances have been updated.
n) Clause 7.2.2.3 of CSA A231.1 and A231.2: Dimensional accuracy requirements have been updated.
o) Clauses 7.3.1 of CSA A231.2: Additional guidance has been included for the specimens.
p) Clause 7.3.2.1 of CSA A231.1: Additional guidance has been included on the spacing of rollers and bearers, steel platen requirements, and rubber strip requirements.
q) Clause 7.3.2.2 of CSA A231.1: Additional guidance has been included for units that do not fit into the testing machine.
r) Clause 7.3.2.3 of CSA A231.1: Additional guidance has been included for dry conditioning.
s) Clause 7.4 of CSA A231.1: For consistency between CSA A231.1 and CSA A231.2, the requirements have been removed and reference to CSA A231.2, Clause 7.4 has been included.
t) Clause 7.3.2 of CSA A231.2: The Note was removed to clarify when concrete should be cut or cored.
u) Clause 7.4.2.5 of CSA A231.2: Additional guidance has been included on the volume of solution relative to the volume of the specimen.
v) Clause 7.4.3 of CSA A231.2: Additional guidance has been included for cutting units.
w) Clause C.1 of CSA A231.2: Language was revised to clarify this section is for segmental paving units other than pavers.
x) Clause D.1 of CSA A231.1: Additional guidance has been included for 200 mm spans between rollers. The Equation has been corrected.

This Standard has been developed in compliance with Standards Council of Canada requirements for National Standards of Canada. It has been published as a National Standard of Canada by CSA Group.

--------------------------------------------------------------------------------------------------------------------------------

CSA A231.1:19 - Precast concrete paving slabs

Scope:

1.1
This Standard specifies requirements for concrete paving slabs manufactured from hydraulic cement concrete to be used in the construction of pavement and roof coverings. Concrete paving slabs either consist of a single concrete throughout or two layers consisting of a backing concrete with a face that has a typical minimum thickness of 4 mm. This Standard includes units with architectural finishes or tactile surfaces.

Notes:
1) Annex A contains information on efflorescence and recommends methods for its removal. Annex B provides information on the installation of pavement components made with precast concrete paving slabs.
2) The terms "slab" and "concrete paving slab" are used interchangeably in this Standard.
3) The terms "height" and "thickness" are used interchangeably in this Standard.

1.2
In this Standard, "shall" is used to express a requirement, i.e., a provision that the user is obliged to satisfy in order to comply with the Standard; "should" is used to express a recommendation or that which is advised but not required; and "may" is used to express an option or that which is permissible within the limits of the Standard. Notes accompanying clauses do not include requirements or alternative requirements; the purpose of a note accompanying a clause is to separate from the text explanatory or informative material. Notes to tables and figures are considered part of the table or figure and may be written as requirements. Annexes are designated normative (mandatory) or informative (non-mandatory) to define their application.

--------------------------------------------------------------------------------------------------------------------------------

CSA A231.2:19 - Precast concrete pavers

Scope

1.1
This Standard specifies requirements for concrete pavers manufactured from hydraulic cement concrete to be used in the construction of pedestrian and vehicular traffic areas. Concrete pavers either consist of a single concrete throughout or two layers consisting of a backing concrete with a face that has a typical minimum thickness of 4 mm.

Notes:
1) Annex A contains information on efflorescence and recommends methods for its removal. Annex B provides information on the installation of interlocking concrete pavements. Annex C contains information about testing and using segmental concrete paving units that do not meet the strict definition of a concrete paver.
2) The terms "paver" and "interlocking concrete paver" are used interchangeably in this Standard.
3) The terms "height" and "thickness" are used interchangeably in this Standard.

1.2
In this Standard, "shall" is used to express a requirement, i.e., a provision that the user is obliged to satisfy in order to comply with the Standard; "should" is used to express a recommendation or that which is advised but not required; and "may" is used to express an option or that which is permissible within the limits of the Standard. Notes accompanying clauses do not include requirements or alternative requirements; the purpose of a note accompanying a clause is to separate from the text explanatory or informative material. Notes to tables and figures are considered part of the table or figure and may be written as requirements. Annexes are designated normative (mandatory) or informative (non-mandatory) to define their application.
