CSA B125.6-17/ASME A112.18.6-17 (R2021)

Preface

This is the second edition of ASME A112.18.6/CSA B125.6, Flexible water connectors. It supersedes the previous edition published in 2009.

The following changes appear in this edition:

a) updated reference to the latest edition of NSF 61;

b) revised working temperatures;

c) new low lead requirements;

d) updated fill valve thread requirements; and

e) updated ice maker pressure drop requirements.

Scope

1.1
This Standard covers flexible water connectors for use in water supply systems under

a) continuous pressure in accessible locations; and

b) intermittent pressure in recreational vehicles only.

1.2
In this Standard, "shall" is used to express a requirement, i.e., a provision that the user is obliged to satisfy in order to comply with the standard; "should" is used to express a recommendation or that which is advised but not required; and "may" is used to express an option or that which is permissible within the limits of the Standard.

Notes accompanying clauses do not include requirements or alternative requirements; the purpose of a note accompanying a clause is to separate from the text explanatory or informative material.

Notes to tables and figures are considered part of the table or figure and may be written as requirements.

Annexes are designated normative (mandatory) or informative (non-mandatory) to define their application.

1.3
SI units are the units of record in Canada. In this Standard, the yard/pound units are shown in parentheses. The values stated in each measurement system are equivalent in application; however, each system is to be used independently. Combining values from the two measurement systems can result in non-conformance with this Standard.

All references to gallons are to U.S. gallons.

For information on the conversion criteria used in this Standard, see Annex B.
