CSA C22.2 No. 182.5-14 (R2019)

Scope

1.1 This Standard applies to photovoltaic connectors:
a) single pole, rated maximum 2000 V dc
b) multi-pole, rated maximum 2000 V ac or dc

1.2 This Standard applies to photovoltaic connectors intended for use in solar photovoltaic systems in accordance with the Canadian Electrical Code, Part I, using stranded copper conductors, for use in either indoor or outdoor nonhazardous locations. Note: Photovoltaic connectors are intended to be installed with cables meeting the requirements of C22.2 No. 271 or equivalent, suitable for the purpose.

1.3 This Standard also applies to panel mounted connectors, splitter connectors, and similar wiring devices intended for use in photovoltaic systems.

1.4 This Standard does not apply to
a) appliance plugs covered in CSA C22.2 No. 57
b) attachment plugs, receptacles, and similar wiring devices intended for use in hazardous locations covered in CSA C22.2 No. 159
c) general use receptacles, attachment plugs, and similar wiring devices covered in CSA C22.2 No. 42
d) industrial type, special use attachment plugs, receptacles, equipment power inlets and outlets, and connectors covered in CSA C22.2 No. 182.1
e) industrial locking type attachment plugs, receptacles, and connectors covered in CSA C22.2 No. 182.2
f) special use connectors covered in CSA C22.2 No. 182.3
