CSA C22.2 NO. 272:20

Preface:

This is the second edition of C22.2 No. 272, Wind turbine electrical systems. It supersedes the previous edition published in 2014. It is one of a series of Standards issued by CSA Group under Part II of the Canadian Electrical Code.

The major changes to this edition include the following:
a) updated the definition of "voltage" to align with the Canadian Electrical Code, Part I;
b) updated the requirements regarding large wind turbine disconnecting means;
c) added requirements to Clause 9.7 on emergency stop devices;
d) added a new Clause (9.9) on high voltage disconnection means; and
e) added a new Clause (13.3.3) on lithium-ion batteries.

For general information on the Standards of the Canadian Electrical Code, Part II, see the Preface of CSA C22.2 No. 0.

This Standard has been developed in compliance with Standards Council of Canada requirements for National Standards of Canada. It has been published as a National Standard of Canada by CSA Group.

Scope:

1.1
This Standard applies to complete wind turbine electrical systems and associated electrical equipment intended for connection at not more than 46 kV and intended for use in accordance with the Canadian Electrical Code, Part I. Products covered by the scope of this Standard are subject to the requirements of CSA C22.2 No. 0.

1.2
This Standard applies to wind turbines of all sizes.

1.3
This Standard does not apply to performance with respect to grid codes or to power performance of wind turbines.
Note: Information on test methods for power performance of wind turbines can be found in CAN/CSA C61400-12-1 and IEC 61400-12-2.

1.4
In this Standard, "shall" is used to express a requirement, i.e. a provision that the user is obliged to satisfy in order to comply with the Standard; "should" is used to express a recommendation or that which is advised but not required; and "may" is used to express an option or that which is permissible within the limits of the Standard. Notes accompanying clauses do not include requirements or alternative requirements; the purpose of a note accompanying a clause is to separate from the text explanatory or informative material. Notes to tables and figures are considered part of the table or figure and may be written as requirements. Annexes are designated normative (mandatory) or informative (non-mandatory) to define their application.

1.5
The values given in SI units are the units of record for the purposes of this Standard. The values given in parentheses are for information and comparison only.
