CSA C22.2 NO. 286-15

This is the first edition of C22.2 No. 286, Industrial control panels and assemblies, one of a series of Standards issued by CSA Group under Part II of the Canadian Electrical Code, Part I.

Industrial control panels were previously certified by extracting the relevant requirements from CSA C22.2 No. 14 and using them in concert with applicable sections of the Canadian Electrical Code, Part I. This Standard is intended to facilitate certification of these products by consolidating all of the applicable requirements in a single standard dedicated solely to industrial control panels.

For general information on the Standards of the Canadian Electrical Code, Part II, see the Preface of CAN/CSA-C22.2 No. 0, General Requirements - Canadian Electrical Code, Part II.

This Standard is considered suitable for use for conformity assessment within the stated scope of the Standard.

This Standard was prepared by the Integrated Committee on Industrial Control under the jurisdiction of the Technical Committee on Industrial Products and the Strategic Steering Committee on Requirements for Electrical Safety, and has been formally approved by the Technical Committee.

Interpretations: The Strategic Steering Committee on Requirements for Electrical Safety has provided the following direction for the interpretation of standards under its jurisdiction: "The literal text shall be used in judging compliance of products with the safety requirements of this Standard. When the literal text cannot be applied to the product, such as for new materials or construction, and when a relevant committee interpretation has not already been published, CSA's procedures for interpretation shall be followed to determine the intended safety principle."

1 Scope

1.1
This Standard applies to control panels and assemblies rated at not more than 1500 V, intended to be installed and used in non-hazardous locations in accordance with the rules of the Canadian Electrical Code, Part I.

Notes:
1) Examples of industrial control panels and assemblies as covered by this Standard may include motor control panels, process control equipment panels, heating panels, programmable control panels, controls for cranes and hoists, heating and cooling control equipment, etc.
2) The term "control" as used throughout this Standard applies to both starters and controllers.
3) Electrical instruments, such as meters, that can be included as part of control equipment are not covered by this Standard.


1.2
The industrial control panels covered by this Standard are intended for use in an ambient temperature of 0 to 40 °C. Additional investigation of the equipment will be required when equipment is to be used in ambient temperature outside of this range.

1.3
This Standard does not apply to equipment or modifications to equipment covered by other CSA Standards, such as:
a) power supplies;
b) automatic transfer switches;
c) elevator equipment;
d) enclosed switches;
e) switchgear;
f) line isolation monitors;
g) panelboards and custom panelboards;
h) hazardous location equipment;
i) hydro-massage equipment;
j) power factor correction capacitor banks;
k) fire pump controllers;
l) assemblies of equipment intended solely for the distribution of power; and
m) motor control centre sections.

1.4
In this Standard, "shall" is used to express a requirement, i.e., a provision that the user is obliged to satisfy in order to comply with the standard; "should" is used to express a recommendation or that which is advised but not required; and "may" is used to express an option or that which is permissible within the limits of the standard.

Notes accompanying clauses do not include requirements or alternative requirements; the purpose of a note accompanying a clause is to separate from the text explanatory or informative material.

Notes to tables and figures are considered part of the table or figure and may be written as requirements.

Annexes are designated normative (mandatory) or informative (nonmandatory) to define their application.
