CSA S347-14 (R2018)

Method of Test for Evaluation of Truss Plates Used in Lumber Joints

CSA Group, 03/01/2014

Publisher: CSA

File Format: PDF

$41.00$83.00


Published:01/03/2014

Pages:29

File Size:1 file , 1.5 MB

Note:This product is unavailable in Russia, Ukraine, Belarus

Scope

1.1 This Standard provides basic procedures based on joint ultimate load or a limiting slip for the determination of the lateral strength resistance and lateral slip resistance of truss plate teeth embedded in sawn and structural composite lumber members.

1.2 This Standard provides for the determination of the lateral strength resistance and lateral slip resistance of nails embedded in lumber members when used in nail-on truss plates. When this Standard is so applied, the word "tooth" is understood to be replaced by the word "nail".

1.3 This Standard provides basic procedures based on truss plate ultimate strength for the determination of the tensile and shear strengths of the net section of the plates.

1.4 The capacities determined by testing methods and procedures described herein, and corrected for the variations in the ultimate tensile strength of the plate material used in the manufacture of the test truss plates, will yield values that may be adjusted for use in engineering design, such as specified in CSA O86.
