CSA Z245.17:22

Preface

This is the first edition of CSA Z245.17, Cold bends . This Standard covers the requirements for factory-made steel cold bends intended to be used for transporting fluids as specified in CSA Z662. As of this edition, induction bends and cold bends have been removed from CSA Z245.11, Steel fittings, and are now covered in CSA Z245.16 and Z245.17, respectively. CSA Group acknowledges that the development of this Standard was made possible, in part, by the valuable dedication of Maros Tropp and the financial support of ATCO Ltd., Benpro Technologies Corp., British Columbia Oil and Gas Commission, Enbridge Inc., FortisBC Energy Inc., TC Energy Corp., and Tectubi Raccordi S.p.A. (Allied Fitting). This Standard was prepared by the Subcommittee on Materials, under the jurisdiction of the Technical Committee on Petroleum and Natural Gas Industry Pipeline Systems and Materials, and the Strategic Steering Committee on Petroleum and Natural Gas Industry Systems, and has been formally approved by the Technical Committee.

Scope

1.1 General This Standard covers the manufacturing of factory-made cold bends, primarily intended for use in oil or gas pipeline systems.

1.2 Size, grade, and category

1.2.1 Size This Standard covers cold bends from outside diameters (ODs) 21.3 to 1219 mm (NPS 1/2 to NPS 48, see CSA Z245.11 Table A.1).

1.2.2 Grade For other than sour service, this Standard covers bends from Grade 241 to Grade 690. For sour service, this Standard covers bends from Grade 241 to Grade 483. Note: The standard grades are 241, 290, 359, 386, 414, 448, 483, 550, 620, and 690 (see Table 3); however, intermediate grades can be used in accordance with Clause 8.2.2. 1.2.3 Category This Standard covers cold bends in the following categories: a) Category I: Cold bends without requirements for proven notch toughness properties; and b) Category II: Cold bends with requirements for proven notch toughness properties.

1.3 Terminology

In the Standard, "shall" is used to express a requirement, i.e., a provision that the user is obligated to satisfy in order to comply with the Standard; "should" is used to express a recommendation or that which is advised but not required; and "may" is used to express an option or that which is permissible within the limits of the standard. Notes accompanying clauses do not include requirements or alternative requirements; the purpose of a note is to separate from the text explanatory or informative material. Notes to tables and figures are considered part of the table or figure and may be written as requirements. Annexes are designated normative (mandatory) or informative (non-mandatory) to define their application.
