CSA Z662:19

Preface:

This is the eighth edition of CSA Z662, Oil and gas pipeline systems. It supersedes the previous editions published in 2015, 2011, 2007, 2003, 1999, 1996, and 1994.

The following are the most significant changes, relative to the previous edition:
a) realignment and removal of duplications with Clause 3 and Annexes A and N;
b) consolidation of transition piece requirements from other clauses for consistency and application in non-sour service;
c) full rewrite of Annex C on limit states design, to improve safety factors for key limit states including revised segmentation and population density assessment area details;
d) segmentation criteria made mandatory in Annex O, revised population density assessment area and a scope extension to include environmental effects of all LVP liquid pipelines;
e) revised requirements for threaded auxiliary connections on flanges;
f) revised requirements for reuse of materials;
g) requirement to have a CGSB Level III review and approve nondestructive inspection procedures;
h) rewording of Clause 7 to clarify welding procedure specification qualification tests and weld procedure specifications;
i) updated requirements for trenchless installations;
j) revisions made to class location assessment areas, class location designations, class location factors, class location changes, and added requirements for designated geographical area;
k) terminology alignment between this Standard and CSA Z245 standards;
l) changes to the interaction rules in Clause 10.10.2.1 to more accurately reflect industry practices for when corrosion features are considered to be interacting;
m) addition of cross-linked polyethylene (PEX) as an acceptable plastic pipe material and PE 80 as an approved material for gas applications;
n) increase in temperature limits of certain types of HDPE to 82 °C;
o) revision to specify Category 1 mechanical fittings only for PE gas distribution applications;
p) rewriting of Annex E to improve general flow and terminology and to remove overlap with other clauses of this Standard;
q) restructuring of Annex N to include facilities and improve integration with Clause 3 and Annex A; and
r) effective pressure cycle management added to the list of considerations to reduce imperfection failures.

The requirements of this Standard are considered to be adequate under conditions normally encountered in the oil and natural gas industry. Specific requirements for abnormal or unusual conditions are not prescribed, nor are all details related to engineering and construction prescribed. It is intended that all work performed within the scope of this Standard meet the standards of safety and integrity expressed or implied herein, and that the requirements of this Standard be applied with due regard to the protection of the environment, which includes land, water, plant life, and animal life. Detailed requirements concerning the protection of the environment are not prescribed.

It is expected that changes will be made from time to time, based on new experience and technology. Where necessary, amendments and supplements will be prepared by the Technical Committee and published in accordance with CSA Group practices.

This Standard has been developed in compliance with Standards Council of Canada requirements for National Standards of Canada. It has been published as a National Standard of Canada by CSA Group.

Scope:

1.1
This Standard covers the design, construction, operation, maintenance, deactivation, and abandonment of oil and gas industry pipeline systems that convey
a) liquid hydrocarbons, including crude oil, multiphase fluids, condensate, liquid petroleum products, natural gas liquids, and liquefied petroleum gas;
b) oilfield water;
c) oilfield steam;
d) liquid or dense phase carbon dioxide; or
e) gas.
Notes:
1) Vapour phase carbon dioxide pipeline systems fall under Item e).
2) Designers are cautioned that the requirements in this Standard might not be appropriate for gases other than natural gas, manufactured gas, vapour phase carbon dioxide, and synthetic natural gas.

1.2
The scope of this Standard, as shown in Figures 1.1 and 1.2, includes
a) for oil industry fluids, piping and equipment in offshore pipelines, onshore pipelines, tank farms, pump stations, pressure-regulating stations, and measuring stations;
b) oil pump stations, pipeline tank farms, and pipeline terminals;
c) pipe-type storage vessels;
d) carbon dioxide pipelines;
e) for gas industry fluids, piping and equipment in offshore pipelines, onshore pipelines, compressor stations, measuring stations, and pressure-regulating stations;
f) gas compressor stations; and
g) gas storage lines and pipe-type and bottle-type gas storage vessels.

1.3
This Standard does not apply to
a) piping with metal temperatures below –70 °C;
b) gas piping beyond the outlet of the customer's meter set assembly (covered by CSA B149.1);
c) piping in natural gas liquids extraction plants, gas processing plants (except main gas stream piping in dehydration and all other processing plants installed as part of gas pipeline systems), gas manufacturing plants, industrial plants, and mines;
d) oil refineries, terminals other than pipeline terminals, and marketing bulk plants;
e) abandoned piping;
f) in-plant piping for drinking, make-up, or boiler feed water
g) casing, tubing, or pipe in oil or gas wells, wellheads, separators, production tanks, and other production facilities;
h) vent piping for waste gases of any kind operating at or near atmospheric pressure;
i) heat exchangers;
j) liquefied natural gas systems (covered by CSA Z276);
k) liquid fuel distribution systems;
l) loading/unloading facilities for tankers or barges;
m) refuelling facilities; and
n) hydrocarbon storage in underground formations and associated equipment (covered by CSA Z341 Series).

1.4
This Standard is intended to establish essential requirements and minimum standards for the design, construction, operation, pipeline system management, and abandonment of oil and gas industry pipeline systems. This Standard is not an application manual for these activities. It is intended to be used by persons competent to make technical judgments in the areas to which this Standard is being applied including engineering, safety, and environmental protection.
Note: Where newly developed materials or processes are used, or unusual conditions are encountered, requirements in addition to those specified in this Standard might be needed.

1.5
The requirements of this Standard are applicable to the operation, maintenance, and upgrading of existing installations. It is not intended that such requirements be applied retroactively to existing installations insofar as design, materials, construction, and established operating pressures are concerned, except as required by Clause 10.7.1 for changes in class location and Clause 10.8.1 for crossings of existing pipelines.

1.6
Unless otherwise stated, to determine conformance with the specified requirements, it is intended that observed or calculated values be rounded to the nearest unit in the last right-hand place of figures used in expressing the limiting value, in accordance with the rounding method of ASTM E29.

1.7
Where any requirements of this Standard ar
