CTA 770.3-E (R2017)

High Definition TV Analog Component Video Interface (Formerly CEA-770.3-E)

Consumer Technology Association (Formerly CEA), 06/25/2013

Publisher: CTA

File Format: PDF

$35.00$70.00


Published:25/06/2013

Pages:24

File Size:1 file , 420 KB

Note:This product is unavailable in Russia, Ukraine, Belarus

This standard defines two raster-scanning systems for the representation of stationary or moving two dimensional images sampled temporally at a constant frame rate. The first image format specified is 1280 x 720 samples (pixels) inside a total raster of 750 lines, as given in Table 1. The second image format specified is 1920 x 1080 samples (pixels) inside a total raster of 1125 lines, as given in Table 1. Both image formats shall have an aspect ratio of 16:9. This standard specifies an analog interface having Y', P'B, P'R color encoding.
