CTA 861-F

A DTV Profile for Uncompressed High Speed Digital Interfaces (Formerly ANSI/CEA-861-F)

Consumer Technology Association (Formerly CEA), 05/01/2013

Publisher: CTA

File Format: PDF

$115.00$230.00


Published:01/05/2013

Pages:186

File Size:1 file , 6.6 MB

Note:This product is unavailable in Russia, Ukraine, Belarus

CEA-861 establishes protocols, requirements, and recommendations for the utilization of uncompressed digital interfaces by consumer electronics devices such as Digital Televisions (DTVs), digital cable, satellite or terrestrial set-top boxes (STBs), and related peripheral devices including, but not limited to DVD players/recorders, and other related Sources or Sinks. CEA-861 is applicable to a variety of standard DTV-related high-speed digital physical interfaces - such as Digital Visual Interface (DVI) 1.0 [4], Open LVDS Display Interface (LDI) [8], and High-Definition Multimedia Interface (HDMI) [52] specifications. Protocols, requirements, and recommendations that are defined include Video Formats and waveforms; colorimetry and quantization; transport of compressed and uncompressed, as well as Linear Pulse Code Modulation (L-PCM), audio; carriage of auxiliary data; and implementations of the Video Electronics Standards Association (VESA) Enhanced Extended Display Identification Data Standard (E-EDID) [9], which is used by Sinks to declare display capabilities and characteristics.
