IEC 60297-3-104 Ed. 1.0 b:2006

Mechanical structures for electronic equipment - Dimensions of mechanical structures of the 482,6 mm (19 in) series - Part 3-104: Connector dependent interface dimensions of subracks and plug-in units

International Electrotechnical Commission, 05/09/2006

Publisher: IEC

File Format: PDF

$47.00$95.00

Description

Published:09/05/2006

Pages:29

File Size:1 file , 480 KB

Note:This product is unavailable in Ukraine, Russia, Belarus

Covers the connector dependent interface dimensions for subracks and plug-in units in accordance with subracks of IEC 60297-3-101. Refers to two-part connectors of IEC 60603-2, IEC 61076-4-101, IEC 61076-4-113 and introduces the related subrack and plug-in unit interface dimensions.
