PDF Preview

IEC 61169-1-4 Ed. 1.0 b:2020

Radio-frequency connectors - Part 1-4: Electrical test methods - Voltage standing wave ratio, return loss and reflection coefficient

International Electrotechnical Commission, 07/08/2020

Publisher: IEC

File Format: PDF

$47.00$95.00


Published:08/07/2020

Pages:26

File Size:1 file , 1.4 MB

Note:This product is unavailable in Ukraine, Russia, Belarus

IEC 61169-1-4:2020 provides test methods for the voltage standing wave ratio, return loss and reflection coefficient of RF connectors, including frequency domain method, time domain method, and gating.

This document is applicable to cable RF connectors, microstrip RF connectors and RF adapters. It is also suitable to RF channels in multi-RF channel connectors and hybrid connectors.
