IEC 61188-7 Ed. 2.0 b:2017

Printed boards and printed board assemblies - Design and use - Part 7: Electronic component zero orientation for CAD library construction

International Electrotechnical Commission, 04/10/2017

Publisher: IEC

File Format: PDF

$72.00$145.00


Published:10/04/2017

Pages:40

File Size:1 file , 1.7 MB

Note:This product is unavailable in Ukraine, Russia, Belarus

IEC 61188-7:2017 establishes a consistent technique for the description of electronic component orientation, and their land pattern geometries. This facilitates and encourages a common data capture and transfer methodology amongst and between global trading partners.
This edition includes the following significant technical changes with respect to the previous edition:
a)   Figure 1 has been corrected;
b)   the term “rectangle” has generally been replaced by “polygon”;
c)   level B has been indicated as preferred level for new libraries.
