IEC /SRD 63200 Ed. 1.0 en:2021

This document, which is a Systems Reference Deliverable, defines the framework elements, associated ontology, and modelling methodology for designing the Smart energy Grid Reference Architecture using the Smart Grid Architecture Model (SGAM), with potential expansion to describe the interaction between the grid and heat/gas systems, and including easily understandable examples.

This document also provides a machine level representation of the concepts associated with the SGAM in the form of an ontology provided in the form of diagrams in Annex A, as well as in the form of a code component. Thus, this document is associated with a code component presented as a ZIP file package containing:

- a file describing the content of the package (IECManifest.xml);
- the OWL representation of the ontology of the concepts introduced in this document;
- The same content as the OWL content, but exposed as a series of HTML files, which any browser can open for easy reading.

Considering that such a code component is redistribuable (EULA license), and can also evolve, it is accessible to all actors of the supply chain through the IEC website at:
http://www.iec.ch/sycsmartenergy/supportingdocuments under the name IEC_SRD_63200.OWL.2021A.Full.zip.

The latest version/release of the document will be found in the future by selecting the file for the code component with the highest value for VersionStateInfo, e.g. IEC_SRD_63200.OWL.{VersionStateInfo}.Full.

Finally, compared to past publications related to the SGAM (mostly by CEN-CENELEC-ETSI CG-SEG), this document provides in addition:
- further refinement on main roles, to avoid possible confusions between them;
- extensions for supporting interfaces for other energies;
- a seamless and detailed integration with the IEC 62559 and IEC 62913 series;
- formal representations in UML and OWL ontology formats.
