IPC 2292

Design Standard for Printed Electronics on Flexible Substrates

Association Connecting Electronics Industries, 03/01/2018

Publisher: IPC

File Format: PDF

$91.00$182.00

Description

Published:01/03/2018

Pages:72

File Size:1 file , 2.7 MB

Note:This product is unavailable in Russia, Belarus

IPC 2292 establishes specific requirements for the design of printed electronic applications and their forms of component mounting and interconnecting structures on flexible substrates. Flexible substrates, as pertain to this standard, are materials or devices which have some amount of flexibility or bendability (not rigid) but are not considered to be stretchable (e.g., fabrics, textiles, stretchable polymers, etc.).
