JEDEC JESD22-B119

MECHANICAL COMPRESSIVE STATIC STRESS TEST METHODS

JEDEC Solid State Technology Association, 10/01/2018

Publisher: JEDEC

File Format: PDF

$26.00$53.00

Description

Published:01/10/2018

Pages:12

File Size:1 file , 170 KB

Note:This product is unavailable in Russia, Ukraine, Belarus

JEDEC JESD22-B119 is intended for customers to determine the ability of a device to withstand the mechanical compressive static stress generated when a heat sink is being initially attached to the device, and to help the customer generate design rules for their heat sink design and validate their thermal solution. This test method does not assess the long-term effects of static stress.
