JEDEC JESD250C

Graphics Double Data Rate 6 (GDDR6) 5GRAM Standard

JEDEC Solid State Technology Association, 02/01/2021

Publisher: JEDEC

File Format: PDF

$114.00$228.00


Published:01/02/2021

Pages:202

File Size:1 file , 3.6 MB

Note:This product is unavailable in Russia, Ukraine, Belarus

This document defines the Graphics Double Data Rate 6 (GDDR6) Synchronous Graphics Random Access Memory (SGRAM) specification, including features, functionality, package, and pin assignments. The purpose of this Specification is to define the minimum set of requirements for 8 Gb through 16 Gb x16 dual channel GDDR6 SGRAM devices. System designs based on the required aspects of this standard will be supported by all GDDR6 SGRAM vendors providing compatible devices. Some aspects of the GDDR6 standard such as AC timings and capacitance values were not standardized. Some features are optional and therefore may vary among vendors. In all cases, vendor data sheets should be consulted for specifics. This document was created based on some aspects of the GDDR5 Standard (JESD212). Item 1836.99E.
