JEDEC JESD305-R8-RCD Version 1.0

DDR5 RDIMM Standard Annex D

JEDEC Solid State Technology Association, 04/01/2022

Publisher: JEDEC

File Format: PDF

$33.00$67.00


Published:01/04/2022

Pages:26

File Size:1 file , 880 KB

Note:This product is unavailable in Russia, Ukraine, Belarus

This standard, JESD305-R8-RCD, DDR5 Registered Dual Inline Memory Module with 8-bit ECC (EC8 RDIMM) Raw Card D Annex, defines the design detail of x8, 1 Package Rank DDR5 RDIMM with 8-bit ECC. The common feature of DDR5 RDIMM, such as the connector pinout, can be found in the JESD305, DDR5 Load Reduced (LRDIMM) and Registered Dual Inline Memory Module (RDIMM) Common Standard.
