JEDEC JESD309-S0-RCA

DDR5 SODIMM Raw Card Annex A. Version 1.0

JEDEC Solid State Technology Association, 06/01/2022

Publisher: JEDEC

File Format: PDF

$127.00$255.22


Published:01/06/2022

Pages:24

File Size:1 file , 540 KB

Note:This product is unavailable in Russia, Ukraine, Belarus

This annex JESD309-S0-RCA, DDR5 Small Outline Dual Inline Memory Module (SODIMM) Raw Card A Annex defines the design detail of x8, 1 Package Rank DDR5 SODIMM. The common feature of DDR5 SODIMM such as the connector pinout can be found in the JESD309, DDR5 Small Outline Dual Inline Memory Module (SODIMM) Common Standard.
